Home > Equipment > 3D Printers > Asiga Max UV
Globally proven layer formation technologies
Every layer is formed under a closely monitored process delivering exceptional consistency and performance.
Asiga SPS™ technology
Providing platform positioning feedback ensuring your build platform is where it needs to before every layer.
Z height precision guaranteed.
Features
Automatic LED power adjustment
Our internal radiometer / light meter provides real-time feedback and automatic cure time adjustment based on actual LED power.
Precise layer curing for every layer.
Industrial grade high-power LED
For optimum material curing choose our UV model which houses a 385nm LED for precise layer curing and ability to process waterclear materials.
Also available with 365nm or 405nm LED.
Production output – Dental Models
Volume
2-3 dental models (lay flat)
Print time
20 minutes @ 100 micron layers
Production output – Dentures
Volume
6-8 denture bases (standing)
Print time
60 minutes @ 100 micron layers
Reliable output for quality assurance and patient safety
Over 93% of data points within 50 microns of the original cad data. Validated by 3Shape.
Technical specifications
| Build Volume X, Y, Z | 119 × 67 × 75mm 4.69 × 2.64 × 2.95 inches |
| Pixel Resolution | 62µm |
| Technology | DLP |
| LED Wavelength | 385nm (high power UV LED) or 405nm |
| Material Compatibility | Asiga materials, 100% Open Material System — use any suitable third party material |
| Software | Asiga Composer software. Lifetime updates included |
| File Inputs | STL, SLC, PLY, STM (Asiga Stomp file format) |
| Network Compatibility | Wifi, Wireless Direct, Ethernet |
| Power Requirements | 100 to 240 VAC, 50/60 Hz, ≤2 Amps |
| System Sizing | 260 × 385 × 370mm / 19.3 kg 10.2 × 15.2 × 14.5 inches / 42.6 lb |
| Packed Sizing | 410 × 500 × 480mm / 21.6 kg 16.1 × 19.7 × 18.9 inches / 47.6 lb |
| Warranty | 12 months manufacturer’s warranty |
| Technical Support | Unlimited lifetime technical support included |
| Bundle Includes | 3D printer, Composer software, 1 kg Asiga material, 1L build tray, Asiga Flash post-curing chamber, calibration toolkit |
Gallery
Videos
Dental Clinic Digital Journey
Asiga Branding Max
Dental Clinic Max UV
How to Import to Composer
Included with your MAX X is everything you need to start printing out of the box.
- MAX X Printer
- Calibration toolkit
- Asiga material of your choice and build tray
- Asiga Flash curing chamber
- Composer software
- Unlimited lifetime technical support
